2024

Liv Devote 1

The Devote was designed to satisfy your gravel wanderlust. Balancing performance and ruggedness, this versatile bike is ready for anything from short cuts through the woods to long, winding trails, as well as crushing your first gravel race.

Select color

Charcoal Plum

Select size

View sizing guide

$2,499.00 AUD

SOLD OUT

Highlights

Lightweight and Sleek
The durable yet lightweight ALUXX-grade aluminium frame with an Advanced-grade composite fork offer a smooth and forgiving ride, handy when you find yourself on the road less travelled. The redesigned geometry puts you in a more performance-oriented position and gives you added control whether you’re picking up speed or detouring downhill to the swimming hole.

Superior Comfort and Control
The Contact XR D-Fuse handlebar features a 5-degree back sweep and flare drop for a comfortable and ergonomic grip. The Contact D-Fuse seatpost can be swapped out for a 30.9mm or 27.2mm round seatpost. These proprietary D-Fuse components absorb bumps and reduce vibrations, ensuring less fatigue and more fun on those epic rides.

Unmatched Versatility
Adapt to the route with the flip chip – dropout, which lets you adjust your wheelbase length and rear-wheel tyre clearance. Go shorter for responsive handling and quick acceleration. Go longer for added stability plus clearance for larger tyres and extra traction.

Technologies

Sizing guide

Size	cm feet
XS	150cm - 163cm 4’11” - 5’4”
S	158cm - 169cm 5’2” - 5’7”
M	164cm - 175cm 5’5” - 5’9”
L	170cm - 181cm 5’7” - 5’11”

Geometry

	XS	S	M	L
Seat Tube Length	XS390	S420	M465	L500
Seat Tube Angle	XS74.5° \| 74.4°	S74.5° \| 74.4°	M74.5° \| 74.4°	L74.5° \| 74.4°
Top Tube Length	XS525 \| 525	S535 \| 535	M545 \| 545	L555 \| 555
Head Tube Length	XS90	S110	M140	L160
Head Tube Angle	XS70.0° \| 69.9°	S70.5° \| 70.4°	M71.0° \| 70.9°	L71.0° \| 70.9°
Fork Rake (mm)	XS50	S50	M50	L50
Trail	XS78.4 \| 82	S75 \| 78.5	M71.6 \| 75.1	L71.6 \| 75
Wheelbase	XS1017 \| 1027	S1024 \| 1034	M1031 \| 1041	L1043 \| 1052
Chain Stay Length	XS430 \| 440	S430 \| 440	M430 \| 440	L430 \| 440
Bottom Bracket Drop	XS80 \| 81	S80 \| 81	M80 \| 81	L80 \| 81
Stack	XS523 \| 524	S544 \| 545	M574 \| 575	L593 \| 594
Reach	XS380 \| 379	S384 \| 383	M386 \| 385	L391 \| 389
Stand Over Height	XS681 \| 688	S708 \| 715	M748 \| 755	L779 \| 786
Stem Length	XS50	S60	M70	L80
Crank Length	XS165	S170	M172.5	L172.5
Wheel Size	XS700	S700	M700	L700

Technical specifications

Size	XS, S, M, L
Colours	Charcoal Plum
Frame	ALUXX-grade aluminum, 12x142mm thru-axle, flat mount disc, flip chip – dropout
Fork	Advanced-grade composite, full-composite OverDrive steerer, 12mm thru-axle, flat mount disc
Shock	N/A
Handlebar	Giant Contact XR D-Fuse, 31.8mm, 5-degree back sweep, flare drop, alloy XS: 400mm, S: 400mm, M: 420mm, L: 420mm
Grips	cork tape with gel
Stem	Giant Contact, +/- 8 degree, alloy XS: 50mm, S: 60mm, M: 70mm, L: 80mm
Seatpost	Giant Contact D-Fuse, alloy, 14mm offset
Saddle	Liv Approach
Pedals	N/A
Shifters	Shimano GRX RX-400, 2x10
Front Derailleur	Shimano Tiagra
Rear Derailleur	Shimano GRX RX-400
Brakes	Shimano GRX RX-400 hydraulic, Giant MPH rotors [F]160mm, [R]160mm
Brake Levers	Shimano GRX RX-400 hydraulic
Cassette	Shimano HG500, 11x34
Chain	KMC X10 with Missing Link
Crankset	FSA Omega Adventure, 32/48 XS: 165mm, S: 170mm, M: 172.5mm, L: 172.5mm
Bottom Bracket	FSA Mega EXA
Rims	Giant S-X2 Disc wheelset, alloy
Hubs	Giant alloy, 12mm thru-axle
Spokes	stainless
Tires	Giant CrossCut AT 2, 700x38c, tubeless
Extras	53mm max tire size in long flip chip position, 45mm max tire size in short flip chip position, tubeless prepared, ISC clamp
Weight	The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
